UNMN

ADF no.: UNL17

Optical Class: 1/1/1/1

Cartridge Size: 133*114*10mm

Viewing Area: 100*93mm

Light State: DIN3

Dark State: DIN5～9/9～13

Shade Control: External & Stepless

Switching Time: 1/10000S±20%

Sensitivity Control: External & Stepless

Delay Time: 0.1S～1S

Power Supply: Li-battery&Solar

Rated Capacity of Li-Battery: 600mAh

Replaceable Battery: Yes

Operating Temp.: -5℃～55℃

Storing Temp.: -20℃～70℃

Arc Sensor: 4

Low Amperage TIG Rated: ≥5amps

Helmet Material: PP

UV/IR Protection: DIN13

Test: Yes

Low Battery: Yes

Grinding: Yes

Cutting: Yes

LED:

ADF no.: UNL18

Optical Class: 1/1/1/1

Cartridge Size: 133*114*10mm

Viewing Area: 100*67mm

Light State: DIN3

Dark State: DIN5～9/9～13

Shade Control: External & Stepless

Switching Time: 1/10000S±20%

Sensitivity Control: Internal & Stepless

Delay Time: 0.1S～1S

Power Supply: Li-battery&Solar

Rated Capacity of Li-Battery: 600mAh

Replaceable Battery: Yes

Operating Temp.: -5℃～55℃

Storing Temp.: -20℃～70℃

Arc Sensor: 4

Low Amperage TIG Rated: ≥5amps

Helmet Material: PP

UV/IR Protection: DIN13

Test: Yes

Low Battery: Yes

Grinding: Yes

Cutting: Yes

LED:

ADF no.: UNL19

Optical Class: 1/1/1/2

Cartridge Size: 133*114*10mm

Viewing Area: 100×93mm(3.94"×3.66")

Light State: DIN3

Dark State: DIN5～9/9～13

Shade Control: External & Stepless

Switching Time: 1/10000S±20%

Sensitivity Control: External & Stepless

Delay Time: 0.1S～1S

Power Supply: Li-battery&Solar

Rated Capacity of Li-Battery: 600mAh

Replaceable Battery: Yes

Operating Temp.: -5℃～55℃

Storing Temp.: -20℃～70℃

Arc Sensor: 4

Low Amperage TIG Rated: ≥5amps

Helmet Material: PP

UV/IR Protection: DIN13

Test: Yes

Low Battery: Yes

Grinding: Yes

Cutting: Yes

LED: Yes
