This synergic MIG welder adapts to operators’ techniques, offering separate voltage adjustment, preset curves and closed-loop constant voltage output with ±15% wide voltage range. It has polarity switching, supports MIG-MAG, MMA, TIG welding and metal cutting.
Designs:
| Parameter | UNMTC‑ 250DBS | UNMTC‑ 250DPS | UNMTC‑ 250DMS |
| Mains Voltage (V) | 220 | 220 | 220 |
| Frequency (HZ) | 50/60 | 50/60 | 50/60 |
| No-load Voltage (V) | 62 | 62 | 62 |
| Rated Capacity (KVA) | 11.3 | 11.3 | 11.3 |
| Cutting Thickness (MM) | ≤18 | ≤18 | ≤18 |
| Wire Dia. (MM) | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 |
| Output Current (A) | 50-250 | 50-250 | 50-250 |
| Rated Duty Cycle (%) | 60 | 60 | 60 |
| Dimensions (CM) | 52*23*39 | 52*23*39 | 52*23*39 |
| Weight (KG) | 15.0 | 15.0 | 15.0 |
individual packing，6pcs/ctn
individual packing，6pcs/ctn
